ACCESSORIES

Industrial
Wireless Remote Foot and Hand Controls
Processes
See literature AY/6.5 (Foot) and AY/6.6 (Hand) TIG (GTAW) Pulsed TIG (GTAW-P)
Stick (SMAW) 1 MIG (GMAW) 1,2
Increases productivity, saves money, improves safety and is easy to use.
Flux-cored (FCAW) 1,2
1 With wireless hand control only.
2 Only with voltage-sensing feeder.
Foot control
Comes complete with
Foot control is designed specifically for TIG welding in Wireless foot control (301580) OR
manufacturing, fabrication and plant applications, allowing hand control (301582) transmitter
operator to adjust amperage at point of use without the Wireless 14-pin receiver (301584)
limitations of a remote cord. Four AA batteries
Auto on/off feature extends the battery life up to 1,500 hours Four Easy-Glide Wear Pads ™
of welding without turning the pedal on and off. (foot control only — sold individually,
248274)
Easy-Glide Wear Pads ™ glide across concrete, making it easy
Wireless to reposition the pedal for comfort and speed. Carabiner clip
foot control (hand control only, 285341)
Wireless 14-pin receiver Wireless
(included with both systems) hand control Hand control Suggested power sources
Hand control is designed for stick, TIG, MIG and flux-cored
Bluetooth® communication technology provides consistent and
welding, allowing operator to adjust parameters for different
reliable connection, allowing precise control of the amperage.
joint configurations, electrodes and wire types/sizes at the
Improves productivity and maneuverability by eliminating cord
point of use instead of walking back to the machine.
tangles. Reduces clean up time and work area cord clutter.
Allows parameter adjustments up to 300 feet away from
Improves reliability and safety by eliminating control cord failures welder without returning to machine.
and reducing potential trip hazards. Look throughout this catalog for the
Improves weld quality. Operators can adjust their machines icon above signifying compatibility
Multiple frequency sharing allows up to 20 systems to operate in a to optimize the parameters for different joint configurations, with a wireless remote.
90-foot (27.4 m) radius with accuracy and precision — and without
electrodes, and wire types and sizes.
delay, system interference, or crosstalk.
Smart Touch ™ buttons allow quick and accurate machine
Easy-to-install receiver plugs directly into the 14-pin receptacle of
parameter adjustments.
Miller® machines.
Digital meter display allows presetting percent age of machine
Easily programmable. Control can be quickly and easily paired with output before welding, and viewing of amperage and voltage
any other Miller® 14-pin wireless receiver. Control is preprogrammed
while welding.
when purchased with the receiver.
*Some applications are not suitable for wireless communication. Keep in mind that the rated range is subjective, and depends on factors
such as obstructions, frequency interference, transmission technology, and weather. The figures listed assume ideal conditions are present.
Model/Stock Number Component Power Supply Battery Life Rated Range* Temperature Radio Frequency RF Power Antenna Dimensions Weight
Wireless Foot Control System Foot control Four AA batteries 1,500 hours 90 ft. (27.4 m) -13° to +122°F 2.4 Ghz (ISM band) <6.31 mW Internal H: 6 in. (152 mm) 3 lb.
301580 (transmitter) (-25° to +50°C) W: 5.75 in. (146 mm) (1.4 kg)
D: 11.5 in. (292 mm) w/batteries
Wireless Hand Control System Hand control Four AA batteries 1,500 hours 300 ft. (91 m) H: 4.9 in. (125 mm) 0.8 lb.
301582 (transmitter) W: 3 in. (76 mm) (0.39 kg)
D: 1.7 in. (44 mm) w/batteries
TIG Accessories (continued) Water-Cooled TIG (GTAW) Torch Connectors
50 mm Thread-Lock-Style
Torch and Weld Cable Connectors
225028
Air-Cooled TIG (GTAW) Torch Connectors 50 mm Dinse-Style Flow Thru For Dynasty 800. Used with
™
273483 1,2 195380 all Weldcraft water-cooled
For Multimatic 215/220 AC/DC and For Syncrowave 210. torches.
Maxstar 161. Used with all Weldcraft ™
25 mm (small) Dinse-style gas thru water-cooled torches.
for one-piece air-cooled torches.
Thread-Lock-Style Weld
194723 A-200 (WP26) Cable Connectors
2
194722 All others 225029
For Syncrowave 210. For Dynasty 800. Contains
50 mm Dinse-style gas thru for 50 mm Dinse-Style with Water two male connectors that
one-piece air-cooled torches. Return Line 195377 accept #1/0 to #4/0 AWG
For Syncrowave 300/400,
size cable.
195379 A-200 (WP26) Maxstar 210/280/400 and
2
195378 All others Dynasty 210/300/400.
For Multimatic 235/255, Used with all Weldcraft ™
CST, Syncrowave 300/400, water-cooled torches.
Maxstar 210/280/400 and
Dynasty 210/300/400.
50 mm Dinse-style for one-piece
air-cooled torches.
1 Except A-200 (WP26) torches. A-80 (WP24) torches require 24-5 adapter.
2
